Chapter 1
| Switch Description
Overview
– 12 –
Key Hardware
Components
This manual describes each specific component, or related components, together
with their installation requirements and procedures in each chapter. To understand
each component in detail, refer to the relevant section.
Figure 1: Switch Front Panels
8
7
1
2
3
6
5
4
9
ECS4620-28T-DC
ECS4620-28P
ECS4620-28F-DC
ECS4620-52T
ECS4620-28T
ECS4620-28F
ECS4620-52P
10
System LEDs 100/1000BASE-X SFP Slots
1000BASE-T RJ-45 Port LEDs 1000BASE-T RJ-45 Ports
10G SFP+ Port LEDs Expansion Module Port LEDs
Combination Gigabit RJ-45/SFP Ports RJ-45 Console Port
10G SFP+ Slots / Stacking Ports USB Port
