– 8 –
Figures
Figure 1: Switch Front Panels 12
Figure 2: Rear Panel 14
Figure 3: Installing the Switch in a Rack 18
Figure 4: Connecting AC Power 19
Figure 5: Connecting DC Power 19
Figure 6: System LEDs 20
Figure 7: Console Port 21
Figure 8: Making a Connection to an RJ-45 Port 22
Figure 9: Switch Cooling 24
Figure 10: Switch Cooling (ECS4620-28T/ECS4620-28T-DC) 25
Figure 11: Attaching the Brackets 27
Figure 12: Installing the Switch in a Rack 27
Figure 13: Attaching the Adhesive Feet 28
Figure 14: Dual-Port 10G SFP+ Module 29
Figure 15: Installing an Optional Module 30
Figure 16: AC Power Supply Socket 31
Figure 17: DC Terminal 32
Figure 18: Redundant Power Supply Connector 33
Figure 19: Grounding Terminal 33
Figure 20: AC Power Cord and Power Socket 34
Figure 21: DC Plug Connections 36
Figure 22: Port Status LEDs 40
Figure 23: Inserting an SFP/SFP+ Transceiver into a Slot 41
Figure 24: RJ-45 Connector 43
Figure 25: Making Twisted-Pair Connections 45
Figure 26: Making a Connection to an SFP+ Port 47
Figure 27: Making Stack Connections 49
Figure 28: System Status LEDs 51
Figure 29: Console Port 52
