Edge EDGE-1830 Original Service Manual

EDGE-1830 EDGE-2440 / EDGE-3240 / EDGE-2460 / EDGE-3260 / EDGE-3860 / EDGE-4460 / EDGE-3270
Original Service Manual 41 Rev 1.6, January 2021
11. Part List
Part No.
Description
135001
Switch Assembly (3pc)
135001.1
Single switch contact block
135002
Fuse Holder
135003
Fuse 3 Amp.
135004
Fuse 10 Amp.
135008
Thermostat Protection, (Bulb-Capillary)
135010
EDGE G2 Control, UI
135011
EDGE G2 Control, MC
135030
Neutral Block
135032-A
Relay, Blower Motor, (Omron) 24VDC
135049
Flame Detector
135055-A
Thermocouple, Type J, 46", Bulb to Receptacle
135056-A
Thermocouple, 42" Extension, Wire to Plug
135057-A
Thermocouple, Type J, 36", Bulb to Receptacle
135130
120mm Cooling Fan Control Box 120VAC 60 HZ
135131
Cooling Fan-Cord
135137
30PPI Filter Media - Cooling Fan
135138-A
Frequency Drive 120VAC primary 240 VAC 3 Phase Secondary, Modbus RTU
135140
Power Supply 120/240 VAC primary 24VDC Secondary, SMPS
135145
Air Switch
135148
Conveyor Drive Motor 24VDC BLDC
135156
Power Receptacle 120VAC
135158
Power Cord 120VAC
135160
Main Motor 240VAC,3 Phase, 3/4HP
135165
Main Motor 120VAC, 1 Phase, 1/3HP
135170
Main Motor Capacitor 7.5uf, 440VAC
135173
Main Motor, 1/2" Strap, SS
135175
Standard Fan, EDGE30
135177
Standard Fan, EDGE40
135179
Standard Fan, EDGE60/40VS
135181
Standard Fan, EDGE3860, EDGE4460, EDGE3270
145162
Window Assy, Large, 60" and larger ovens, (35.250")
145163
Window Assy, Small, 40" ovens and smaller (24.250")
145180
Knob-End Plug, BLK 1/4-20x3/8
145280
Cog, Conveyor Belt, All Models
145282
Sprocket-Conveyor Drive, Standard, 15T, SS Key, All Models
145284
Sprocket-Conveyor Drive, Standard, 10T-1/2 Bore, Control Can Side, All Models
145290
Belt-Conveyor, 12" Belting, per foot (24x.072,12",5 Spaces, C-CureEdge)
145292
Belt-Conveyor, 15" Belting, per foot (24x.072,15",5 Spaces, C-CureEdge)
145294
Belt-Conveyor, 18" Belting, per foot (24x.072,18",7 Spaces, C-CureEdge)
145295
Belt-Conveyor, 21" Belting, per foot (24x.072,07 Spaces, C-CureEdge)
145296
Belt-Conveyor, 24" Belting, per foot (24x.072,11 Spaces, C-CureEdge)
145298
Belt-Conveyor, 32" Belting, per foot (24x.072,31.94,11 Spaces, C-CureEdge)
145300
Belt-Conveyor, 38" Belting, per foot (24x.072,38",15 Spaces, C-CureEdge)
145302
Belt-Conveyor, 44" Belting, per foot (24x.072,44",15 Spaces, C-CureEdge)
