EDGE-1830 EDGE-2440 / EDGE-3240 / EDGE-2460 / EDGE-3260 / EDGE-3860 / EDGE-4460 / EDGE-3270
Original Service Manual 5 Rev 1.6, January 2021
Touch the UP/DOWN arrows to adjust the temperature. Touch the CHECK to accept or the X to cancel.
Repeat this method for Time and for the Fan Speed (Hz).
❖ Advanced Operation
Change Recipe:
- Touch and hold the recipe namespace on the display for 1-2 seconds.
- Select the desired recipe using the UP/DOWN arrows, touch CHECK to accept.
-*Special items in this menu are:
- ‘<NEW>’ used to define a new recipe based on the current setting of ‘MANUAL’
- ‘MANUAL’ is a “test and tune” mode, allows easy adjustment of the baking parameters
CUSTOMER PIN is required (see CUSTOMER PIN).
Create a New Recipe:
- Define the new recipe in ‘MANUAL’ operation mode.
- Touch and hold the on-screen ‘MANUAL’ namespace for 1-2s.
- Select ‘<NEW>’ from the menu, CUSTOMER PIN is required.
- Define the recipe name (See Recipe NAMESPACE).
- Define/Verify Temp, Time, and Hz (60 is standard).
You may store up to 30 recipes. MANUAL mode is primarily for tuning a recipe, although unsecure,
the oven may be operated in this mode without ever defining a recipe.
Change a Recipe:
- Selecting the recipe (see Change Recipe).
- Touch and hold the recipe namespace on the display until a PIN entry screen appears.
Customer PIN is required.
- Advance through the parameters (Namespace, Temp, Time, Hz), adjustment as needed.
Deleting a Recipe:
- Selecting the recipe (see Change Recipe).
- Touch and hold the recipe namespace on the display until a PIN entry screen appears.
Customer PIN is required.
- In the Namespace adjustment, select ‘<DEL RCP>’.
- The control will default to ‘MANUAL’.
