- 28 -
ENGLISH
INSTALLATION
9(56,21:,7+*/$666,'(6$1'723
7he stove is delivered with the sides and top removed and
protected for the transportation phase.
7o remove the protection, proceed as follows:
- Remove the glass top (A - ¿g. 1-2-) by cutting the straps
(B - ¿g. 1) that secure it to the stove and remove the protection
(& - ¿g. 2) placed between it and the cast iron top.
- Open the door and remove the galvanised panel (D - ¿g. 4)
- Slacken the wing nuts at the lower and upper ends on the
inside of the glass sides (EF -¿g. 56).
- &lose the door and remove the plating pro¿les on the back
(* - ¿g. 7).
- 7ake the glass sides off (+ - ¿g. 8) and remove the protection
- Remove the rubber pads ¿[ed under the ¿[ing brackets for
the glass sides (I - ¿g. 9)
- Remove everything and the repeat the steps listed in reverse
order
9(56,21:,7+67((/6,'(6$1'*/$66
TOP
7he stove is delivered with the sides and top ¿tted, complete
with protection for the glass top for the transportation phase.
7o remove the protection from the top, proceed as indicated
above.
¿g. ¿g. 4
¿g. 6
F
¿g. 5
D
A
E
¿g. 7
G
¿g. 1 ¿g. 2
A
¿g. 8
¿g. 9
H
I
C
B
