- 29 -
ENGLISH
INSTALLATION
)/8(287/(7$77+(723
MYA is set up to allow the Àue pipe to be connected at the top
or the back.
7he stove is delivered ready for the Àue pipe to be ¿tted at the
back.
7o allow the Àue pipe to be connected at the top, the speci¿c
optional e[tra kit must be used (code
760680). 7he kit includes the following parts:
- N 1 80 clamp (L)
- N 1 inspection elbow (M)
- N 1 Àue pipe outlet (3)
- N 2 top Àue pipe outlet closers (4)
7o ¿t the kit, proceed as follows:
)RUWKHYHUVLRQZLWKJODVVVLGHV
- Remove the supported glass top (A - ¿g. 1).
- Open the door and remove the galvanised panel (B - ¿g. 2)
- Slacken the wing nuts at the lower and upper ends on the
inside of the left side (&D -¿g. 4).
- &lose the door and remove the plating pro¿les on the back
(E - ¿g. 5).
- Remove the glass side (F - ¿g. 6) removing the clamps (* -
¿g. 6).
- 7hen proceed to ¿t the kit as indicated on the ne[t page.
)RUWKHYHUVLRQZLWKVWHHOVLGHV
- Remove the supported glass top (+ - ¿g. 7).
- Remove the side steel, ¿[ed to the structure of the stove with
2 screws (X - Fig. 7) to remove, pulling it upwards (I - Fig. 8)
- 7hen proceed to ¿t the kit as indicated on the ne[t page.
¿g. 1 ¿g. 2
¿g. 4
¿g. 5
¿g. 6
D
¿g.
B
A
C
E
F
G
G
¿g. 7
¿g. 8
H
I
X
X
