Edimax IC-7001W - Page 74

70
Hold your mouse cursor over any icon for a description of its function.
Descriptions are also included below:
Item
Description
Video display area
The image of all connected cameras will be displayed
here.
Language
Select a language from this dropdown menu to change
the display language.
Display layout
Change camera image display layout (Click a layout
icon to change camera display layout). There are 8
kinds of display layouts available.
Full screen
Click this button to switch to full screen mode (only
display all camera’s image), press ‘ESC’ key to quit full
screen mode.
Scan
Click this button and the network camera surveillance
software will switch through the images of all
connected camera automatically. Click this button
once to activate the scan function (scan icon will
become blue ), click again to stop scanning (scan
icon will become white ).
PTZ control
There are 4 directions in the Pan Tilt Zoom (PTZ)
control ring. If the camera you connect to supports
PTZ, you can use the PTZ control ring to change the
direction that the camera faces.
This function is only available for supported cameras.
Home
Click this button to return the camera to ‘Home’
(default) position.
This function is only available for supported cameras.
Recording
Start video recording.
Configure
Software / camera configuration.
Playback
Play back a recorded video file.
Snapshot
Take a snapshot of current the camera image.
Message display
Displays all system messages.
