25
VLAN Mode/ID
Displays the VLAN ID for the specified WDS.
See IV-3-1-4. WDS
Refresh
Click to refresh all information.
Client Bridge Mode:
Wireless 2.4GHZ (5GHz) / SSID
Connection Status
Current status of the repeater’s connection.
Source SSID
Displays the SSID name(s) for the repeater’s
source.
Authentication
Method
Displays the authentication method for the
specified SSID. See IV-3. Wireless Settings
Encryption Type
Displays the encryption type for the specified
SSID. See IV-3. Wireless Settings
MAC Address
Displays the access point’s MAC address.
Channel
Displays the channel number the specified
wireless frequency is using for broadcast.
Transmit Power
Displays the wireless radio transmit power
level as a percentage.
