I-2. System Requirements
- Existing cable/DSL modem & router
- Computer with web browser for access point configuration
I-3. Hardware Overview
A. LAN1 port with Power over Ethernet (Passive PoE) IN.
B. LAN2 port with Power over Ethernet (Passive PoE) OUT.
C. Reset the access point to factory default settings
D. SMA connector for optional antenna.
E. Switch the LAN2 (Passive PoE) OUT on/off.
A LAN1 (PoE) IN
E PoE Out On/Off
D SMA
C Reset
