IRC-3 / ZAS-1 Sensitivity Report
[OP-008.CDR]
- - - Alarm Trip Level - - -
Type Trbl Normal Alert Lev1 Lev2 Lev3 Lev4
1.Photo 0400 520-1400 1550 1710 1940 2170 2390
2.Ion 0400 600-1200 1550 1810 1940 2010 2110
3.Thermal 0400 500-1200 2000
4.Monitor 0600 750-1300 1400
5.Control 0600 750-1300 1400
6.ZA/B Zn 0400 610-1250 1440
7.RZB Zn 0600 750-1150 1450 2300
8.AA Sec 0960 1120-1550 1760
note: **** indicates device failed communications.
Current Device or Zone Levels:
Address Type Trip Present Verf
Lev Lev Counts
01 05 01 1120 00
16 05 01 1070 00
07 04 01 1050 00
21 04 01 1080 00
25 04 01 1110 00
03 05 01 1110 00
18 05 01 0980 00
11 04 01 **** 00
22 04 01 1060 00
26 05 01 1030 00
05 04 01 1060 00
19 05 01 1000 00
14 05 01 1080 00
23 04 01 1040 00
27 04 01 1050 00
06 04 01 1080 00
20 04 01 1090 00
15 05 01 1020 00
24 04 01 1090 00
28 04 01 1160 00
= = = = Panel Sensitivity Report = = = =
Date: 11-03-94
Time: 01:08:17
Panel Address: 02
Operational Level Table:
------------------------------------------------------------------------------
ZAS-2 Sensitivity Report
Refer to the figure below which shows a sample IRC-3 / ZAS-2
sensitivity report.
• The header information at the top of the report indicates the address
of the specific panel tested, along with the time and date of the test.
• The Current Device Level Table lists the address, type, alarm
threshold, and maintenance indicator for all Signature Series 3D and
