INSTALLATION
D395-90-880 Issue E
3 INSTALLATION
3.1 Unpack and inspect
Remove all of the packaging material and check the ADC. If the Controller is damaged, follow the Edwards return of
equipment procedures that are laid out in the back of this manual. Do not use the Controller if it is damaged.
Check that your package contains the items that are listed in Table 5. If any of these items are missing, notify your
supplier in writing within three days. If the Controller is not to be used immediately, store the Controller in suitable
conditions as described in Section 6.1.
3.2 Fitting the controller
CAUTION
Ensure that the unit is installed where fluids cannot enter into the Controller. The Controller is IP20 rated, and
therefore has no protection against fluid ingress.
3.2.1 Bench-top mounting
The ADC can be used on a bench-top. Figure 4 shows the dimensions of the Controller that are required for bench
top use. The self-adhesive non-slip feet may be fitted to the bottom of the Controller if required.
Figure 4 - Bench mounted dimensions (mm)
Table 5 - Component checklist
Quantity Description Check (3)
1 Active Digital Controller
2 Panel mounting clamps
4Non-slip feet
WARNING
Ensure that all wiring is safely secured so that people cannot trip on them.
