Edwards E2M0.7 User Manual

A371-32-880 Issue C
Page 6 © Edwards Limited 2007. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.3 Mechanical data
2.4 Electrical data
The motor start-up current is drawn for less than one second, so you must use slow-blow fuses to prevent unnecessary
fuse failure when the pump starts. If you use the pump at temperatures lower than 12 °C (53.6 °F), the start-up
current will be drawn for longer; this may cause the motor thermal overload device to open.
Approximate pump mass 10 kg (22 lbs)
Dimensions See Figure 2
Degree of protection (IEC34-5:1981) IP44
Pump inlet port NW10 (the flange can be removed from the
3
/
8
inch BSP tapped hole)
Pump outlet port 11 mm external diameter nozzle (the nozzle can be removed from
the
3
/
8
inch BSP tapped hole)
Noise level at 1 metre 54 dB(A)
E2M0.7 pump
Motor output rating – continuous 0.09 kW
Motor electrical supply Single phase
E2M1 and E2M1.5 pumps
Motor output rating – continuous 0.16 kW
Motor electrical supply Single phase
Table 1 – Electrical data
Pump
Nominal supply
(V)
Frequency
(Hz)
Full load current
(A)
Start-up current
(A)
Maximum fuse
rating (A)
*
*
Fuses should be EN60269 Section 2.2 or to BS 1362.
E2M0.7 100-115 50 1.8 5.7 10
100-120 60 1.9 5.3 10
200-230 50 0.85 2.8 6
200-240 60 1.0 2.3 6
E2M1 and E2M1.5 100-115 50 3.1 12.0 10
100-120 60 3.0 11.2 10
200-230 50 1.3 5.5 6
200-230 60 1.4 5.2 6
