A371-32-880 Issue C
Page 30 © Edwards Limited 2007. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Service, spares and accessories
7.4.8 Outlet mist filter
The outlet mist filter separates and traps oil droplets in the pump outlet to prevent oil mist discharge.
7.4.9 Oil drain extension
Fit the oil drain extension between the oil drain port on the pump and the oil drain-plug to make the drainage of oil
from the pump easier. The pack includes an oil drain extension tube for use when oil is gravity drained.
7.4.10 Vibration isolators
The vibration isolators reduce transmission vibration and noise when the pump is floor or frame mounted and to help
to reduce strain when the mounting area is uneven.
7.4.11 Pump inlet or outlet NW25 adaptor
This is a 3/8 inch BSP to NW25 adaptor, supplied with connection hardware. Use this adaptor when you remove the
NW10 adaptor fitted to the pump-inlet or the outlet-nozzle fitted to the pump outlet, to adapt the 3/8 inch BSP
thread to NW25.
Product Item Number
EMF3 Outlet mist filter A462-20-000
Product Item Number
Oil drain extension A505-03-000
Product Item Number
Vibration isolators (pack of four) A248-01-407
Product Item Number
Pump inlet adaptor A371-01-028
