Technical data
D396-14-880 Issue J
2.4 Electrical connectors
2.5 Factory settings
Table 6 - Electrical connectors data
Electrical supply connector socket type CEE/IEC 320
Earth (ground) stud (on rear panel) M4
Backing pump relay connector
*
*
Not applicable to the EXC120E Controller.
Socket type Stak 200
Maximum voltage 250 V a.c.
Maximum current (a.c. r.m.s. inductive load,
0.8 pf lagging) 15 A
Bakeout band connector
*
Socket type CEE/IEC 320
Maximum power 150 W
Active gauge connector
Signals on the connector pins See Figure 16 and Table 1 1
Socket type FCC68, 8-way
Manufacturer Western Electric
Maximum power 3 W
Logic interface connector
Socket type (EXC120/120E/300M) MVSTBR 2,5/17-st5,08
Socket type (EXC300) MVSTBR 2,5/18-st5,08
Manufacturer Phoenix Combicon
Table 7 - Factory settings
Normal speed setpoint 80% of full rotational speed
Internal Timer 8 min, enabled
Vent options See Table 10
Logic interface: pins linked on the mating connector
EXC120/E Pins 8 & 9, pins 12 & 13, pins 14 & 15
EXC300/M Pins 9 & 10, pins 13 & 14, pins 15 & 16
