Edwards GXS 160/1750 - Figure 2 Front View of the Pumping System with the Side Exhaust and Skids Fitted

Figure 2 Front view of the pumping system with the side exhaust and skids ed
1
2
6
5
4
3
CS/1060/A
1. Front panel controls 2. Floor mounng plate (4 o)
3. Exhaust gas outlet connecon 4. Liing eyebolts (4 o)
5. Pumped gas inlet connecon 6. RF earth (ground) cable
1. Front panel controls 2. Floor mounng plate (4 o)
3. Exhaust gas outlet connecon 4. Liing eyebolts (4 o)
5. Pumped gas inlet connecon 6. RF earth (ground) cable
