© Edwards Limited 2008. All rights reserved. Page 11
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
A590-00-880 Issue D
2.4 Connections
Table 5 - iH connector types
Description
Mating connector description / external
supply rating
Internal supply
rating
Electrical supply connector Harting HAN-K-4/2 16 mm
2
wire, 18 to
27 mm cable OD
1 - Phase 1 (R)
2 - Phase 2 (S)
3 - Phase 3 (T)
Pump display terminal connector XLR type 5-way plug 24 V d.c. 0.75 A
Network LON communications connector XLR type 4-way plug 24 V d.c. 0.75 A
Exhaust gas management interface DIN type 6-pin plug
1 - normally open and 3 - common 30 V a.c. 1 A
2 - normally open and 4 - normally closed 30 V a.c. 1 A
3 - normally open and 6 - common 60 V d.c. 0.5 A
Active gauge connector
*
*
Optional accessory.
SCC68 socket
Exhaust TMS power supply
†
†
HTX variants only.
Edwards TMS type
Tool interface module connector / EMS XLR type 6-way plug
1 and 2 - linked, remove - normally closed
3 and 4 - isolated auxiliary contacts
5 - continuous output 24 V a.c. 625 mA
6 - return
Tool interface adapter (iTIM) D type 15-way plug
External emergency stop switch 24 V a.c. 5 A
(load 700 mA
inductive)
