STP Series Turbomolecular Pump
MT-00E-001-M
Page 32
INSTALLATION OF THE STP CONTROL UNIT
3
3.2 Cable connection
Refer to the STP Control Unit Instruction Manual (C) for detailed information of the cables.
3.2.1 STP connection cable
Figure 23 - SCU-350 series STP connection cable
Figure 24 - SCU-800/801 STP connection cable
Figure 25 - SCU-1600/1601 STP connection cable
