Technical Data
MODEL EMT2.5 EMT4
Capacity gallons 2.5 4.0
Voltage Vac 110-120 110-120
Power at 120 Vac Watts 1440 1440
Max. Water Pressure psi 150 150
Weight (empty) lbs. 20 24
Amperage Amps 12 12
Temperature and
Pressure Relief Valve
Water inlet
Water outlet
water outlet
water inlet
Assembly Figure
Water Flow Figure
Page 3
Eemax mini tank manual.indd 4 5/30/2008 10:44:50 AM
