EES USM - Validity

General notes
Page 4 of 72 MSM-USM2G-BA-UK-004
1 Validity
The description applies to all USM blocks from software version 3.5.0 with the following options:
59
U
x
x
x
x
x
x
x
x
x
Number of reporting inputs
A
8 reporting inputs
B
16 reporting inputs
W
16 reporting inputs in the wide housing (96 x 192mm)
C
24 reporting inputs
D
32 reporting inputs
E
40 reporting inputs
F
48 reporting inputs
Operating voltage
1
24 V AC/DC
2
48 - 60 V AC/DC
5
110 - 220 V AC/DC
Signal voltage
1
24 V AC/DC
3
48 - 60 V AC/DC
4
110 V AC/DC
H
125 V AC/DC
5
220 V AC/DC
W
50 - 250 V AC/DC (Weitbereich)
IT security functionality
E
Basic version, no IT security functionality
S
Security configuration, IT Security acc. to BDEW guidelines
P
Port Security, enhanced security configuration incl. option S
1st Interface card
W
Modbus TCP + IEC60870-5-101/-104
F
Modbus TCP + IEC60870-5-101/-104 + IEC 61850
2nd Interface card
0
none
W
Modbus RTU/TCP + IEC60870-5-101/-104
L
Modbus RTU/TCP + IEC60870-5-101/-104, fibre optic interface Type SC
LED color
D
parameterizable (red, green)
R
parameterizable (red, green, yellow, orange, blue, white)
Additional cards
0
none
R
1:1 relay (for 8 - 48 way fault annunciators)
1
8 relay outputs (independent of no. of inputs)
2
16 relay outputs (independent of no. of inputs)
A
4, 8, 10 or 12 way analog inputs (for 8, 16, 24 or 40 way fault annunciators)
3
4 analog inputs (independent of the fault annunciator’s size)
4
8 analog inputs (independent of the fault annunciator’s size)
5
8 relay outputs + 4 analog inputs
(independent of the fault annunciator’s size)
6
16 relay outputs + 4 analog inputs (only for 24 way fault annunciators)
7
8 relay outputs + 8 analog inputs (only for 24 way fault annunciators)
Table 1.1: Matrix of USM devices
