Parameterization
6.1 Alarm channels and IEC objects
Further information on the parameters can be found in the section Submenu Reporting channel.
6.1.1 Alarms
Index (idx)
The index is a consecutive number which ensures that the original sequence is reproducible when
sorting the table according to certain contents.
Device number and input
The column device number (0…3) indicates the device that is addressed (master annunciator (0) or
one of the up to three slaves (1…3)).
The column input addresses the alarm channel on the respective device.
The values entered in these columns have to be consistent.
Signal name 1 and 2
The content of these two fields is used for the parameter „Signal name“ of the reporting channels in
the parameterization interface. To gain a 3-lined labelling , a third line can be generated in the field
„signal name 2“ by inserting a „\“ as separation between lines 2 and 3.
Operation / Normally closed
The respective function (operation indication or processing of the input in normally closed principle)
can be activated with „x“ or „X“. If the field is empty, the respective function is not activated.
The Excel-file has to be of the type .xls, other Excel formats cannot be processed by the
annunciator.
The name of the tab „EES_Input“ must not be changed, otherwise the tab will not be
processed during the import.
