Parameterization
Acknowledge 1, 2, 3,
unassigned
Acknowledgement optical for alarms of groups 1, 2 ,3 or unassigned
alarms
Reset 1, 2, 3, unassigned
Reset for alarms of the collective alarm groups 1, 2 or 3 or unassigned
alarms (only needed when 2-frequency reporting sequence is
activated)
Acknowledgement acoustic (horn)
Simulation of the excitation of all inputs
As long as this operating mode is activated, the horn is not triggered or
automatically acknowledged after the parameterized time.
As long as this operating mode is active, there is no visual or audible
output of pending alarms. The internal alarm processing and, if
necessary, the control of relays or the output of alarms via interface
remain active. Alarm acknowledgement at the fault annunciator is
deactivated.
Table 5.4: Assignment of buttons and function inputs
The assignment is made in form of a matrix whose rows represent the functions and whose
columns represent the buttons and function inputs. Realized links are marked by check
marks.
A group is formed by all alarms that are included in the same collective alarm.
Unassigned alarms are alarms that do not belong to a collective alarm.
