Controls & Connections
❹
Foot pedal
receptacle
Air input Power input
receptacle
Vacuum
transducer
Voltage selector and
fuse cartridge
Barrel
vacuum control
Air output
quick-connect
Power
switch
❸
❷
Air pressure
regulator
❶
Air gauge
120
