EFD 800 User Manual

First: Unpack and use the checklist enclosed with
the Dispenser Kit to identify all items. If there is
any discrepancy, please call us immediately.
Second: Power and compressed plant air should
be available where the dispenser is to be set up.
Air pressure should be between 80 and 100 psi
(5.5 and 6.9 bar). If you are not using an EFD five-
micron filter regulator #2000F755, be certain
your plant air is properly filtered and dry.
Bottled nitrogen can be used.
Warning: If high pressure bottled air or nitrogen is
used, a high pressure regulator must be installed
on the bottle and set up at 100 psi maximum. The
#2000F755 filter regulator is not required.
Check the voltage label to be certain it is set to
the available power.
Third: Now is a good time to ACTIVATE your
extended Two Year Limited Warranty. Please fill
in and return the postage paid Warranty card. Or
if you prefer, call the appropriate toll-free number
listed below, provide the serial number of your
dispenser and respond to a few short questions.
You are then assured of complete protection for
two years.
US, call 800-556-3484.
In Mexico, call 001-800-556-3484.
In the UK, ring free 0800 585733.
This manual is for the express and sole use of EFD dispenser purchasers
and users, and no portion of this manual may be reproduced in any form.
EFD, ULTRA System, LV Barrier, SmoothFlow, ZeroDraft, SafetyLok,
SnapLok and DispenStand are trademarks of EFD Inc. ©2001 EFD Inc.
Contents
Dispenser Hookup.................................... 4-5
Controls & Connections .............................. 6
Setup for Testing......................................... 7
Testing the Dispenser ................................. 8
Using the Vacuum Control .......................... 9
ULTRA Dispensing System.................. 10-11
Loading the Barrel Reservoirs.............. 12-13
Suggestions & Reminders......................... 14
Components Reorder................................ 15
Two Year Limited Warranty....................... 16
Meets applicable CSA and CE requirements.
Reference CSA LR File Number 84105
First Steps
☎

EFD 800 Specifications

General

Brand	EFD
Model	800
Category	Dispenser
Language	English
