Direction 1
Direction 2
Negative
Positive
Direction 1
Direction 2
Negative
Positive
BQ1 = CRANE SLEWING DRIVE
BQ2 = 1ST BOOM DRIVE
BQ3 = 2ND BOOM DRIVE
BQ4 = STANDARD CRANE EXTENSION DRIVE
BQ5 = WINCH DRIVE
BQ6 = CS1 SUPPL. CONTROL DRIVE
BQ7 = CS2 SUPPL. CONTROL DRIVE
WIRE MARKING / CRANE FUNCTION
CONTROL BANK TYPE HAWE
CONTROL BANK TYPE DANFOSS
ITEM CODE PRINTED ON THE LOWER SIDE OF THE DMU
MAIN BOX
CONTROL BANK LEVER MICROSWITCH BY-PASS
