NOTE: Letters in (parentheses) refer to the PARTS IDENTIFIER on page 2 and/or the PARTS ASSEMBLY on page 3. Use as needed for clarification.
FOLDING PLATFORM
38. Align the bottom of the Folding Platform (H) with the Lower Rails (K) just above the
Lower Rail Base (J).
39. Using the two holes just above the Lower Rail Base (J), slide the fixed pin into the hole
in the outside left Lower Rail as you face the Tower (A).
40. Pull the retractable pin on the right side and move the pin over the hole. Release the pin.
41. Move the Folding Platform (H) until all the pins engage completely.
38
39
40
41
