22
NOTE: Letters in (parentheses) refer to the PARTS IDENTIFIER on page 2 and/or the PARTS ASSEMBLY on page 3. Use as needed for clarification.
FOLDING AND STORAGE (CONTINUED)
67.
Pull the rails into A-frame position, making sure the Support Strut Knob (M) remains
disengaged.
68. Push the Rails (K, X) and the Tower (A) together. Stand the Lower Rail Base (J) on the
Tower Base (P).
IMPORTANT NOTES:
69. When storing your PowerTower
TM
, hang the Handles (U) out of the way, making sure that
Dynamic Arm Pulley System (D) cables remain free from contact with hinges, the floor,
or wheels.
To move the PowerTower, stand behind the Tower (A), grasp the Tower (A) top, pull back in
hand truck fashion and roll. To unfold PowerTower and return it to use, see the beginning of
these instructions.
NOTE: Be sure to secure the Handles (U) away from the Tower Base (P) and Transport Wheels (Q)
before moving.
OPTIONAL ACCESSORY
70. WEIGHT BAR
71. The Weight Bar lets you add standard plate weights to the PowerTower to achieve greater
resistance.
Observe the instructions provided with each accessory.
67 68
69
70
71
