EG4 EG4-LL-S User Manual

29
General Specifications
Parameter
Spec
Condition
Cell Balance 120mA Passive Balance
Cell Voltage Difference
>40mV
Temperature Accuracy 3%
Cycle
Measurement
Measuring Range -40°F ‒
212°F (-40°C ‒ 100°C)
Voltage Accuracy 0.5%
Cycle
Measurement
For Cells & Module
Current Accuracy 3%
Cycle
Measurement
Measuring Range -200A -
200A
SOC 5% / Integral Calculation
Power Consumption
Sleep & Off
Mode
<300uA Storage/Transport/Standby
Power Consumption Operating Mode <25mA Charging/Discharging
Communication Ports RS485/CAN Can be customized
Maximum Modules in Series 1
Maximum Modules in
Parallel
64
Physical Specifications
Dimensions (H×W×D)
6.1 in.×19 in.×17.4 in. (15.5 cm×48.2 cm×44.2 cm)
Weight
99.6 lbs. (45.2 kg)
Standards and Certifications
Module
ETL Listed to UL Standard 9540A:2019
Cell
UL:1973
