LINE TRIMMER ATTACHMENT — STA1500
9
SPECIFICATIONS
Cutting Mechanism Bump Head
Line Diameter
2.4 mm nylon
twist line
Cutting Width 38 cm
No-Load Speed
5000/6000
min
-1
Weight (Without battery pack) 1.59 kg
Recommended Operating
Temperature
0°C-40°C
Recommended Storage Temperature -20°C-70°C
Sound pressure level 70 dB(A)
◾ The above parameters are tested and measured
equipped with power head PH1400E.
PACKING LIST
PART NAME QUANTITY
Line Trimmer Attachment 1
Guard 1
Hex Wrench 1
Multi-Function Wrench 1
Operator’s Manual 1
About recommended cutting line, please visit the website
egopowerplus.com or refer to the EGO Product Catalogue.
DESCRIPTION
KNOW YOUR LINE TRIMMER ATTACHMENT (Fig. A)
1. End Cap
2. Line trimmer Shaft
3. Cutting Line
4. Trimmer Head (Bump Head)
5. Release Tab
6. Line-cutting Blade
7. Guard
8. Hex Wrench
9. Multi-Function Wrench
10. Out ange (For brush cutter head only)
11. Nut (For brush cutter head only)
WARNING: Never operate the tool without the guard
rmly in place. The guard must always be on the tool to
protect the user.
ASSEMBLY
WARNING: If any parts are damaged or missing,
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING: Do not attempt to modify this product
or create accessories not recommended for use with this
line trimmer. Any such alteration or modication is misuse
and could result in a hazardous condition leading to
possibly serious personal injury.
WARNING: Do not connect to power head until
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
MOUNTING THE GUARD
WARNING: Always wear gloves when mounting or
replacing the guard. Be careful of the blade on the guard
and protect your hands from being injured by the blade.
Loosen and remove the two screws from the guard (Fig. C),
align the guard mounting holes with the assembly holes
and then lock the guard onto the shaft base with the two
screws, together with two spring washers (Fig. D).
Make sure the guard is xed according to Fig. C & D, any
reverse xing will cause great danger!
CONNECTING THE LINE TRIMMER ATTACHMENT TO
THE POWER HEAD
This line trimmer attachment is designed for use with EGO
Power Head PH1400E.
See “ INSTALLING AN ATTACHMENT TO THE POWER HEAD
“ section in the power head PH1400E operator’s manual.
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.
WARNING: Always wear eye protection, along with
hearing protection. Failure to do so could result in objects being
thrown into your eyes and other possible serious injuries.
APPLICATIONS
You may use this product for the purpose listed below:
◾ Trimming grass and weeds from around porches,
fences, and decks
