Eighteeth E-CONNECT - Technical and Compliance Information; Technical Data

33
26、Technical Data
Manufacturer
Changzhou Sifary medical technology Co.,Ltd
Model
E-CONNECT
Dimensions
20cm x 17.5cm x7cm (package)
Weight
700g
Contra-angle
Contra-angle compatible with rotary and reciprocating
instruments, equipped with a 2.35 mm shaft
conforming to ISO 1797-1:2011, Type 1
Power supply
Lithium ion battery: 3.7V, 1500mAh
Charger power supply
AC100-240V
Frequency
50/60Hz
Charger nominal power input
5.5VA
Torque range
0.5Ncm-4Ncm
Speed range of the micromotor
shaft
120-1000 rpm
Electrical safety class
Class II
Applied part
BF
Ambient conditions
Use: in enclosed spaces
Ambient temperature: 10°C / 40 °C
Relative humidity: <80%; non-condensing at 0°
Operating altitude < 2000 m above sea level
Transport and storage
conditions
• Ambient temperature: -20 °C / +55 °C
• Relative humidity: 20% - 80%, non-condensing
at > 40 °C
• Atmospheric pressure: 50 kPa - 106 kPa
