Eighteeth NanoPix2 - Image Acquisition and Viewing Procedures

5. Soft Introduction
Page 29 / 66
5.5 Oral X-ray Image Acquisition Menu
The main page of Oral X-ray Image Acquisition Menu
：
IO Sensor
ACQUISITION: Click it and enter the oral X-ray Image Acquisition
Menu interface.
90CCW: Use to rotate image 90° counterclockwise.
90CW: Use to rotate image 90° clockwise.
Flip Horizontal: Use to make image mirror left and right.
Flip Vertival: Use to make image mirror up and down.
NEW STUDY: represents the data source.
IO Sensor: data comes from the sensor;
Import: data comes from local.
