6. Operation
Important! Always switch the appliance off and
unplug the power plug before making any adjust-
ments.
6.1 Insert the chain that is to be sharpened
into the chain bar (Fig. 7)
To do this, loosen the chain locking screw (1)
6.2 Set the grinding angle according to the
specifi cations for your chain (Fig. 8) (nor-
mally between 30-35°)
•
Slacken the locking screw for setting the grin-
ding angle (1)
•
Set the desired grinding angle using the scale
(2)
•
Tighten the locking screw (1) again
6.3 Set the chain stopper (Fig. 9/10)
•
Fold the chain stopper (1) onto the chain
•
Pull the chain backwards against the chain
stopper (1) until the latter stops a cutting link
(A). Important! You must make sure that the
angle of the stopped cutting link coincides
with the grinding angle. If it does not, pull the
chain one link further.
•
Fold the grinding head (4) down until the grin-
ding wheel (5) is touching the chain link (A)
that is to be ground. (To do so, you can move
the chain back and forth a little using the set-
ting screw of the chain stopper (2)
6.4 Set the depth limit (Fig. 10)
Fold the grinding head (4) down and set the grin-
ding depth using the setting screw (7)
Important! The grinding depth should be set
so that the full cutting edge of the cutting link is
sharpened.
6.5 Lock the chain (Fig. 7)
Tighten the chain locking screw (1)
6.6 Grinding the chain links (Fig. 10/11)
Important!
•
Only use the equipment for sharpening saw
chains. Never grind or cut other materials.
•
Before sharpening the saw chain clamp it into
the chain bar. This will prevent jamming of the
grinding wheel caused by a loose saw chain.
•
Slowly guide the grinding wheel to the saw
blade. If the grinding wheel approaches the
saw chain too quickly or jerkily, this may
cause damage to the grinding wheel. Injuries
may result from catapulting parts!
•
Switch the appliance on at the ON/OFF
switch (1)
•
Carefully bring the grinding wheel (5) with
grinding head (4) so that it is against the set
link
•
Switch the appliance off at the ON/OFF
switch (1). Every second link in the chain
must be sharpened in this way. To know when
every second link in the entire chain has been
sharpened, mark the first link (e.g. with chalk).
Once all cutting links on one side have been
sharpened, the grinding angle must be set
to the same number of degrees on the other
side. You can then begin to sharpen the links
of the other side(without having to make any
further adjustments).
6.7 Set the depth limiter spacing (Fig. 12/13)
Once the chain has been fully sharpened, you
must make sure that the depth limiter spacing is
kept (the depth limiters (1) must be lower than the
cutting links (2). You may need to fi le the depth
limiters (1) to the specifi cations for your chain
using a fi le (3) (not included in delivery).
7. Replacing the power cable
Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
Anl_GC_CS_85_E_SPK1.indb 20Anl_GC_CS_85_E_SPK1.indb 20 03.05.16 11:5703.05.16 11:57
