EINHELL JS SERIES User Manual

Table 3 - JS SERIES SAWS parts list
(Note: Use Figure 18 to Figure 24 to locate item numbers. See section 7.4 for item #53 breakdown. JS SERIES
SAWS parts are the same except for item #22.)
ITEM
QUANTITY
PART NUMBER
DESCRIPTION
1
1
FOAM GRIP
2
1
SX77144
DEADMAN SWITCH LEVER
3
2
SX78119
POINTER WHEEL
4
1
SX77141
HANDLE
5
1
SX77155
COVER/DEADMAN SWITCH
6
2
SX78117
3/8"-16X4" HEX HEAD BOLT, FULL THREAD
7
3
SX73722
3/8"-16X2" HEX HEAD BOLT
8
2
SX84200
6"X2" M/O WHEEL BEARING
9
1
SX77116
ARM/POINTER 7"
10
11
SX73723
NUT/HEX LOCK 3/8"
11
2
SX75208
1-1/2" OPEN END WRENCH
12
2
SX71520
#10-32X3/8" PHIL PAN HEAD
13
8
SX60474
WASHER/FLAT 3/4"
14
1
SX77120
CHASSIS
15
12
SX92019
WASHER/FLAT 3/8"
16
1
SX77125
BLADE GUARD
17
1
SX98020
3/8" LOCK WASHER
18
1
SX77167
LOWER JACK ASSEMBLY ARM
19
1
SX60184
2"HR 3/8"-16 STEM CASTER
20
1
SX77135
BELT GUARD
21
7
SX92011
NUT/HEX 3/8"-16UNC
22
1
VARIES
MOTOR
23
1
SX92013
DUST BRUSH/BLADE GUARD
24
1
SX78116
POINTER ARM 24"
25
12
SX63730
5/16" FLAT/WASHER
26
4
SX63722
5/16"-18X1" HEX HEAD BOLT
27
2
SX91529
3/8"-16X3" HEX HEAD BOLT
28
2
SX91024
3/8"-16X1-1/2" HEX HEAD BOLT
29
2
SX80207
3/8"-16X1" HEX HEAD BOLT
30
1
SX77024
BLADE SHAFT 1"
31
6
SX63723
1/8"X1" COTTER PIN
32
1
SX77127
FRAME/FRONT AXLE
33
2
SX90177
BEARING/FLANGE 2 BOLT 1" BORE
34
1
SX80501
JS OUTER FLANGE W/PIN
35
1
SX80503
JS DRIVE FLANGE
36
1
SX92000
2" V-RIB BELT SHEAVE, 10 RIBS, J CROSS
SECT.
37
1
SX92017
POLY V BELT -280J10
38
1
SX73706
KNOB/CLAMPING 3/8"-16 STUD
39
1
SX90210
3"X3" RUBBER COUPLER
40
4
SX80502
JS 1/4" SPACER
41
4
SX78108
1/2" NYLOCK NUT
