7.4 Jack assembly part
number:
05-77162
EM
QUANTITY
CATALOG
NUMBER
1
1
05-77158
2
1
05-77161
3
1
05-9801 1
4
1
05-77160
5
2
05-98014
05-98013
DESCRIPTION
CRANKARM
LIFTING ROD-3/4"-10UNC
ROLL PIN/03/16" X 1" LONG
HEIGHT CONTROL/UPPER
WASHER/NYLON 1/2" X 1-1/4" X
1/16" THICK
WASHER/STEEL 1/2" X 1-1/16" X
.10" THICK
Table 5 - Jack assembly parts list
(Note: Use Figure 24 to locate item numbers. Jack
assembly is the same for the JS SERIES SAWS .)
Figure 24 - Jack assembly exploded view
27

EINHELL JS SERIES Specifications

General

Type	Jigsaw
Variable Speed	Yes
Stroke Rate	Varies depending on the model
Bevel Cut	Yes
Pendulum Action	4-stage
Blade Change	Tool-less
