1.0 Instructions for use of manual sections
Read this entire operations and maintenance manual before using your new tool. Pay close attention to the
Rules for safer operation, Dangers, Warnings and Cautions.
The purpose of safety symbols and explanations are to attract your attention to possible hazards and how to
avoid them. The safety symbols and explanations do not by themselves eliminate any danger. The
instructions or warnings they give are not substitutes for proper accident prevention measures.
DANGER: Indicates an imminently hazardous situation that if not avoided, will result in death or serious
injury. This signal word is limited to the most extreme situations.
WARNING
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or serious
injury.
CAUTION
CAUTION: Indicates a potentially hazardous situation that, if not avoided may result in minor or moderate
injury. It may also be used to alert against unsafe practices that may cause property damage.
2.0 Specifications
JS SERIES SAWS engine:
JS SERIES SAWS engine:
Fuel type:
Oil type & capacity:
JS SERIES SAWS Weight:
JS SERIES SAWS weight:
Blade speed:
Blade diameter sizes:
Blade depth cut:
Blade type:
Overall size:
Blade nut wrench size:
Shaft diameter:
Flanged bearing grease:
Assembly part numbers:
Recommended dust
collector system:
Vacuum hose size:
Operating &
maintenance manual
revision number:
Honda 13 HP Gas Powered
5HP 230v 1P, 5HP 208/480v 3P
Unleaded gasoline, 86 octane or higher
SAE10W-30, 1.16qt
160 pounds Gas
180 pounds Electric
5850 rpm maximum
8" and 10"
3" with 10" blade, 2" with 8" blade
Dry diamond, 1" arbor hole, & single drive pinhole
28.3" WX 35.5" LX 37.5" H
1-1/2"
1"
ALVANIA® Grease 3 every 100 hours
JS SERIES SAWS 13 hp GAS SX77130
230v 1P Electric SX77100
208/480v 3P Electric SX77104
U.S. SAWS Mega-Vac Electric SX24550
4"
JS Series Revised 1/1/2011
U.S. SAWS Mega -Vac Gas SX24555
SX24555
