EINHELL TC-EW 160 D User Manual

GB
- 17 -
3. Proper use
The electric welder can be used to weld various
metals using the appropriate coated electrodes.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Symbols and technical data
EN 60974-6
European standard for arc welding sets and wel-
ding power supplies with limited on time (Part 6).
S
Symbol for welding power supplies which are sui-
table for welding in environments with increased
electrical danger.
~ 50 Hz
Alternating current and rated frequency value [Hz]
U
0
Rated idling voltage [V]
160 A/ 24.4 V
Maximum welding current and the corresponding
standardized operating voltage [A/V]
Ø
Electrode diameter [mm]
U
2
Welding voltage [V]
I
2
Welding current [A]
—
Highest welding time rated value in continuous
mode tON (max) for highest welding current rated
value at an ambient temperature of 20 °C, ex-
pressed in minutes and seconds.
- - -
Highest welding time rated value in intermittent
mode tON for highest welding current rated
value at an ambient temperature of 20 °C over an
uninterrupted time of 60 min, expressed in minu-
tes and seconds.
t
w
Average load time [s]
t
r
Average reset time [s]
1(3) ~ 50 Hz
Line input; number of phases, the alternating cur-
rent symbol and the rated frequency value
U
1
Line voltage [V]
I
1max
Highest rated value of the line current [A]
I
1eff
E ective value of the highest line current [A]
IP 21 S
Protection type
H
Insulation class
쓑
Symbol for protection class II
Welding times depend on the power which is
taken from the equipment. At high power the ON
period is shorter and the cooling time longer; at
low power the ON period is longer and the cooling
time shorter.
Overheating guard
Electrode tongs
Earth terminal
Anl_TC_EW_160_D_SPK9.indb 17Anl_TC_EW_160_D_SPK9.indb 17 26.07.2017 09:01:0026.07.2017 09:01:00

EINHELL TC-EW 160 D Specifications

General

Fuse	16 A
No-load voltage	48 V
AC input voltage	230/400 V
AC input frequency	50 Hz
Welding processes	-
Maximum welding current	160 A
Minimum welding current	55 A
Variable welding current	Yes
Maximum electrode diameter	4 mm
Minimum electrode diameter	1.6 mm

Weight and Dimensions

Depth	480 mm
Width	280 mm
Height	356 mm
Weight	20450 g
