EINHELL TC-SM 216 User Manual

GB
- 25 -
Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Danger!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fi re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
Special information about the laser
 Caution! Laser radiation
Do not look into the beam
Laser class 2
VORSICHT ! - LASERSTRAHLUNG !
Nicht in den Strahl blicken!
Laserspezifikation
Laser Klasse 2
Ǹ: 650 nm; P
0
ƓʸÃ
Ä·¹¾ʽʷʿʹʼƖʸ
•
Never look directly into the laser path.
•
Never direct the laser beam at reflecting sur-
faces or persons or animals. Even a low out-
put laser beam can inflict injury on the eye.
•
Caution: It is vital to follow the work proce-
dures described in these instructions. Using
the equipment in any other way may result in
hazardous exposure to laser radiation.
•
Never open the laser module.
•
It is prohibited to carry out any modifications
to the laser to increase its power.
•
The manufacturer cannot accept any liability
for damage due to non-observance of the
safety information.
2. Layout and items supplied
2.1 Layout (Fig. 1-3)
1. Handle
2. On/Off switch
3. Release button
4. Machine head
5. Saw shaft lock
6. Adjustable blade guard
7. Saw blade
8. Clamping device
9. Guide for workpiece support
10. Workpiece support
11. Locking grip for workpiece support
12. Screw for workpiece support
13. Fixed stop rail
14. Movable stop rail
15. Locking grip for movable stop rail
16. Table insert
17. Adjustable foot
18. Fixed saw table
19. Turntable
20. Locking lever
21. Release button
22. Pointer (turntable)
23. Scale (turntable)
24. Pointer (miter)
25. Scale (miter)
26. Locking grip
27. Sawdust bag
28. Discharge opening
29. Locking screw for drag guide
30. Retaining pin
31. Knurled screw for cutting depth limiter
32. Lock nut for cutting depth limiter
33. Stop plate for cutting depth limiter
34. Screw for cutting depth limiter
35. Adjustment screw for angle stop 90°
36. Adjustment screw for angle stop 45°
37. Lock nut for angle stop
38. Flange bolt
39. Outer fl ange
40. Washer
41. Laser
42. On/Off switch for laser
43. Transport handle
44. Adjustment screw for stop rail
45. Hexagon key 6mm
46. Screw for transport handle
Anl_TC_SM_216_SPK9.indb 25Anl_TC_SM_216_SPK9.indb 25 24.04.2019 09:30:4624.04.2019 09:30:46

EINHELL TC-SM 216 Specifications

General

Blade bore	30 mm
Blade diameter	216 mm
Saw blade included	Yes
Number of blade teeth	48
Input power	1500 W
Power source	AC
AC input voltage	220 -240 V
AC input frequency	50 Hz
Idle speed (max)	5200 RPM
Cutting width (90°)	305 mm
Sliding rails	-

Weight and Dimensions

Depth	790 mm
Width	460 mm
Height	380 mm
Weight	12740 g
Package weight	14840 g
