EINHELL TC-SM 2531 U User Manual

GB
- 22 -
Danger! Read the operating instructions to reduce the risk of inquiry
Caution!Wear ear-muff s. The impact of noise can cause damage to hearing.
Caution! Wear safety goggles. Sparks generated during working or splinters, chips and dust emitted
by the device can cause loss of sight.
Caution! Wear a breathing mask. Dust which is injurious to health can be generated when working on
wood and other materials. Never use the device to work on any materials containing asbestos!
Caution! Risk of injury! Do not reach into the running saw blade.
Warning! The adjustable stop rail is fastened with a wing nut.
To make miter cuts (inclined saw head or rotary table with angle adjustment), the adjustable stop rail
must be fi xed at the outer position.
For 45° miter cuts to the left, the left stop rail must be moved outwards and fi xed in position.
To make 90° crosscuts, the adjustable stop rail must be fi xed at the inner position.
Anl_TC_SM_2531_U_SPK7.indb 22 21.08.15 08:20

EINHELL TC-SM 2531 U Specifications

General

Input power	1800 W
Power source	AC
Blade bore	30 mm
Blade diameter	254 mm
Idle speed (max)	4800 RPM
Dust extraction	Yes

Weight and Dimensions

Depth	790 mm
Width	460 mm
Height	422 mm
Weight	21200 g
