EINHELL TC-TS 200 User Manual

GB
Anl_TC_TS_200_SPK9.indb 24 13.11.2019 12:55:56
CV) It is prohibited to use any type of HSS saw
blade and cutting-off wheel.
To use the equipment properly you must also
observe the safety information, the assembly
instructions and the operating instructions to be
found in this manual.
All persons who use and service the equipment
have to be acquainted with these operating
instructions and must be informed about the
equipment‘s potential hazards. It is also
imperative to observe the accident prevention
regulations in force in your area. The same
applies for the general rules of health and
safety at work. The manufacturer will not be
liable for any changes made to the equipment
nor for any damage
resulting from such changes. Even when the
equipment is used as prescribed it is still
impossible to eliminate certain residual risk
factors. The following hazards may arise in
connection with the machine‘s construction and
design:
• Contact with the saw blade in the uncovered
saw zone.
• Reaching into the running saw blade (cut
injuries).
• Kick-back of workpieces and parts of
workpieces.
• Saw blade fracturing.
• Catapulting of faulty carbide tips from the
saw blade.
• Damage to hearing if essential ear-muffs are
not used.
• Harmful emissions of wood dust when used
in closed rooms.
4. Technical data
Mains voltage: ..........................230-240V ~
50Hz Power: .........................500 W S1, 800 W
S6 15% Idle speed n
0
: .......................................
2950 rpm Carbide saw blade: .........Ø 200 x Ø 16
x 2.4 mm Maximum tooth pitch
............................... 2.4 mm Number of teeth:
............................................ 24 Table size:
.....................................505 x 373 mm Max.
cutting height: ......................... 45 mm / 90°
........................................................ 27 mm / 45°
Dust extraction connector: ....................Ø 36 mm
Weight: ....................................... approx. 11.6
kg Thickness of the splitter: ......................... 2.2
mm
Operating mode S6 15%: Continuous operation
with idling (cycle time 10 minutes). To ensure
that the motor does not become excessively hot,
it may only be operated for 15% of the cycle at
the specifi ed rating and must then be allowed to
idle for 85% of the cycle.
Danger!
Noise
The noise emission values were measured in
accordance with EN 62841.
Operation
L
pA
sound pressure level ..................... 87.2
dB(A) K
pA
uncertainty ........................................
3 dB(A) L
WA
sound power level .....................
100.2 dB(A) K
WA
uncertainty
........................................ 3 dB(A)
Wear ear-muff s.
The impact of noise can cause damage to
hearing.
The stated noise emission values were
measured in accordance with a set of
standardized criteria and can be used to
compare one power tool with another.
The stated noise emission values can also be
used to make an initial assessment of exposure.
Warning:
The noise emission levels may vary from the
level specifi ed during actual use, depending on
the
- 21 -

EINHELL TC-TS 200 Specifications

General

Input power	800 W
AC input voltage	230-240 V
AC input frequency	50 Hz
Idle speed	2950 RPM
Cutting depth (45º)	27 mm
Cutting depth (90º)	45 mm
Number of teeth	24
Saw blade included	-
Package depth	510 mm
Package width	540 mm
Package height	360 mm
Package weight	13600 g
Product color	Black, Red, Stainless steel

Weight and Dimensions

Weight	11000 g
Table depth	373 mm
Table width	505 mm
Bore diameter	16 mm
Blade diameter	200 mm
