5-3. Specifications
LCD Panel 76 cm (29.8 inch), TFT color LCD panel
Surface treatment : Anti-Glare Hard Coating
Surface hardness : 3H
Response Time : 12ms
Viewing Angle Horizontal : 178°, Vertical : 178°
(CR: 10 or more)
Dot Pitch 0.2505mm
Horizontal Scan Frequency 26~100 kHz
Vertical Scan Frequency 29.5 - 30.5Hz, 59 - 61Hz (VGA TEXT: 69 ~ 71 Hz)
Resolution 2560 dots x 1600 lines
Display Colors 16.77 million colors (max.)
Recommended Brightness 120cd/m
2
or less (with color temperature of between 5000K to 6500K)
Display Area 641.2 mm (H) × 400.8 mm (V) (25.2" (H) x 15.8" (V))
Power Supply 100-120 VAC±10%, 50/60 Hz, 1.8A
200-240 VAC±10%, 50/60 Hz, 0.8A
Power Consumption Max.
Min. (Normal)
Power Saving Mode
Power switch Off
:170 W (with USB)
:81W (without USB)
:Less than 2 W (for single signal input without USB)
:1W or less
Input Signal Connector
SIGNAL 1:DVI-D, Dual Link
SIGNAL 2:DVI-D, Single Link (HDCP compliant)
Input Signal (Digital) TMDS
Signal registration 10
Plug & Play VESA DDC 2B / EDID structure 1.3
Dimensions with stand 689 mm (W) x 511.5 ~ 629.5 mm (H) x 254.7 mm (D)
(27.1"(W) x 20.1" ~ 24.8" (H) x 10"(D))
without stand 689 mm (W) x 450 mm (H) x 90 mm (D)
(27.1"(W) x 17.7" (H) x 3.54"(D))
with hood 699 mm (W) x 520 ~ 638 mm (H) x 406.5 mm (D)
(27.5"(W) x 20.5" ~ 25.1" (H) x 16"(D))
Weight with stand 15.7 kg (34.6 lbs.)
without stand 11.2 kg (24.7 lbs.)
with hood 17 kg (37.5 lbs.)
Environment
Conditions
Temperature Operating
Storage
: 0°C ~ 35°C (32°F ~ 95°F)
: -20°C ~ 60°C (-4°F ~ 140°F)
Humidity Operating
Storage
: 30% to 80% R.H. Non-condensing
: 30% to 80% R.H. Non-condensing
Pressure Operating
Storage
: 700 to 1060 hPa.
: 200 to 1060 hPa.
USB standard USB Specification
Revision 2.0
USB port Upstream port x 1
Downstream port x 2
Communication Speed
480 Mbps (high), 12 Mbps (full), 1.5 Mbps (low)
Power Supply Downstream: 500 mA for each (max.)
