16
Chapter2AdjustingScreens
●
EV2416W
Analog Input (D-Sub)
Resolution Applicable Signals
Vertical Scan
Frequency
Dot Clock
640×480 VGA 60Hz
193.3MHz
(Max.)
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×720
*1
CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1600×1200 VESA 60Hz
1680×1050 VESACVT,VESACVTRB 60Hz
1920×1200
*2
VESACVT,VESACVTRB 60Hz
Digital Input (DVI-D)
Resolution Applicable Signals
Vertical Scan
Frequency
Dot Clock
640×480 VGA 60Hz
162MHz
(Max.)
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×720
*1
CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1600×1200 VESA 60Hz
1680×1050 VESACVT,VESACVTRB 60Hz
1920×1200
*2
VESACVTRB 60Hz
Digital Input (DisplayPort)
Resolution Applicable Signals
Vertical Scan
Frequency
Dot Clock
640×480 VGA,CEA-861 60Hz
162MHz
(Max.)
720×480(4:3) CEA-861 60Hz
720×480(16:9) CEA-861 60Hz
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×720
*1
CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1600×1200 VESA 60Hz
1680×1050 VESACVT,VESACVTRB 60Hz
1920×1200
*2
VESACVTRB 60Hz
*1 For this resolution, the “Screen Size” setting is “Full Screen” (see “2-5. Screen Size Changing” (page 29)).
*2 Recommended resolution
