Chapter6Reference
●
EV2416W
Resolution
Applicable
Signals
Frequency Polarity
Dot Clock:
MHz
Horizontal:
kHz
Vertical: Hz Horizontal Vertical
640×480 VGA 25.18 31.47 59.94 Negative Negative
800×600 VESA 40.00 37.88 60.32 Positive Positive
1024×768 VESA 65.00 48.36 60.00 Negative Negative
1280×720 CEA-861 74.25 45.00 60.00 Positive Positive
1280×960 VESA 108.00 60.00 60.00 Positive Positive
1280×1024 VESA 108.00 63.98 60.02 Positive Positive
1600×1200 VESA 162.00 75.00 60.00 Positive Positive
1680×1050 VESACVT 146.25 65.29 59.95 Negative Positive
1680×1050 VESACVTRB 119.00 64.67 59.88 Positive Negative
1920×1200 VESACVT 193.25 74.56 59.89 Negative Positive
1920×1200 VESACVTRB 154.00 74.04 59.95 Positive Negative
●
EV2436W
Resolution
Applicable
Signals
Frequency Polarity
Dot Clock:
MHz
Horizontal:
kHz
Vertical: Hz Horizontal Vertical
640×480 VGA 25.18 31.47 59.94 Negative Negative
640×480 VESA 31.50 37.86 72.81 Negative Negative
640×480 VESA 31.50 37.50 75.00 Negative Negative
720×400 VGATEXT 28.32 31.47 70.09 Negative Positive
800×600 VESA 36.00 35.16 56.25 Positive Positive
800×600 VESA 40.00 37.88 60.32 Positive Positive
800×600 VESA 50.00 48.08 72.19 Positive Positive
800×600 VESA 49.50 46.88 75.00 Positive Positive
1024×768 VESA 65.00 48.36 60.00 Negative Negative
1024×768 VESA 75.00 56.48 70.07 Negative Negative
1024×768 VESA 78.75 60.02 75.03 Positive Positive
1280×720 CEA-861 74.25 45.00 60.00 Positive Positive
1280×960 VESA 108.00 60.00 60.00 Positive Positive
1280×1024 VESA 108.00 63.98 60.02 Positive Positive
1280×1024 VESA 135.00 79.98 75.03 Positive Positive
1600×1200 VESA 162.00 75.00 60.00 Positive Positive
1680×1050 VESACVT 146.25 65.29 59.95 Negative Positive
1680×1050 VESACVTRB 119.00 64.67 59.88 Positive Negative
1920×1200 VESACVT 193.25 74.56 59.89 Negative Positive
1920×1200 VESACVTRB 154.00 74.04 59.95 Positive Negative
