Eizo FlexScan EV2430 User Manual

45
Chapter 6 Reference
6 -7. Specications
LCD Panel Size 24.1-inch (611 mm)
Type TFT color LCD, LED backlight
Surface treatment Anti-Glare Hard Coating
Viewing angles Horizontal 178˚, vertical 178˚ (CR≥10)
Dot Pitch 0.270 mm
Response Time Gray-to-gray: 14 ms
Horizontal Scan
Frequency
Analog 31 - 76 kHz
Digital DVI 31 - 76 kHz
DisplayPort 31 - 76 kHz
Vertical Scan
Frequency
Analog 55 - 61 Hz (non-interlace)
Digital DVI 59 - 61 Hz (non-interlace)
DisplayPort 59 - 61 Hz (non-interlace)
Resolution 1920 Dots × 1200 Lines
Max. Dot Clock Analog 202.5 MHz
Digital DVI 162 MHz
DisplayPort 162 MHz
Max. Display Color Approx. 16.77 million colors
Display Area (H × V) 518.4 mm × 324.0 mm
Power Supply 100 - 240 VAC ±10 %, 50 / 60 Hz 0.65 A - 0.35 A
Power
Consumption
Screen Display On 36 W or less
Power saving mode 0.3 W or less (with no USB connections, “EcoView Sense”: “Off”, and
“Sound” - “Power Save”: “Sound Off”)
Power Off 0.3 W or less
Main Power Off 0 W
Input Signal Connector D-Sub mini 15-pin
DVI-D connector (Applicable to HDCP)
DisplayPort (Standard V1.1a, applicable to HDCP)
Applicable Format (Audio signal)
- 2ch linear PCM
(32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz)
Analog Input Signal (Sync) Separate, TTL, positive / negative
Analog Input Signal (Video) Analog, Positive (0.7 Vp-p / 75 Ω)
Digital Signal (DVI) Transmission System TMDS (Single Link)
Audio Output Speaker output: 1.0 W + 1.0 W
Headphone output: 2 mW + 2 mW (32 Ω)
Dimensions
(Width) ×
(Height) ×
(Depth)
Main unit 552.5 mm × 368 - 499 mm × 233 mm
Main unit (without
stand)
552.5 mm × 358 mm × 56.9 mm
Mass Main unit Approx. 6.7 kg
Main unit (without
stand)
Approx. 4.3 kg
Movable range Tilt: 35˚ Up, 5˚ Down
Swivel: 344˚
Adjustable height: 140 mm (131 mm for tilt of 0˚)
Rotation: 90˚ (Clockwise)
