7-3. Specications
LCD Panel Type IPS (Anti-Glare)
Backlight LED
Size 23.8” (60.5 cm)
Resolution 1920 dots × 1080 lines
Display Size (H × V) 527.0 mm × 296.5 mm
Pixel Pitch 0.275 mm × 0.275 mm
Display Colors 8-bit colors: 16.77 million colors
Viewing Angle
(H / V, typical)
178˚ / 178˚
Response Time
(typical)
Gray-to-gray: 14 ms (overdrive setting: O)
5 ms (overdrive setting: Enhanced)
Video Signals Input Terminals DisplayPort (HDCP 1.3 compatible) × 1, HDMI (HDCP 1.4 compatible)
*1
× 1,
USB-C (DisplayPort Alt Mode, HDCP 1.3 compatible) × 1
Output Terminal USB-C (DisplayPort Alt Mode) × 1
Digital Scanning
Frequency
(H / V)
DisplayPort: 31 kHz to 68 kHz /
59 Hz to 61 Hz,
69 Hz to 71 Hz (at 720 × 400)
HDMI: 31 kHz to 68 kHz /
59 Hz to 61 Hz,
69 Hz to 71 Hz (at 720 × 400)
USB-C (DisplayPort Alt Mode): 31 kHz to 68 kHz /
59 Hz to 61 Hz,
69 Hz to 71 Hz (at 720 × 400)
Frame
Synchronization
Mode
49 Hz to 61 Hz
Max. Dot Clock 148.5 MHz
USB Port Upstream USB-C (USB 3.1 Gen 1)
*2
× 1
USB-B (USB 3.1 Gen 1) × 1
Downstream USB-C (USB 3.1 Gen 1)
*3
× 1
USB-A (USB 3.1 Gen 1) × 3
Standard USB Specication Revision 3.1 Gen 1
Communication
Speed
5 Gbps (super), 480 Mbps (high), 12 Mbps (full), 1.5 Mbps (low)
Power
Supply
Upstream USB-C (USB 3.1 Gen 1): Maximum 70 W
(5V/3A, 9V/3A, 12V/3A, 15V/3A,
20V/3.5A)
Downstream USB-C (USB 3.1 Gen 1):
USB-A (USB 3.1 Gen 1):
Max. 3000 mA / 1 port
*4
Max. 900 mA / 1 port
*4
Audio Audio Input Format DisplayPort: 2ch linear PCM (32 kHz / 44.1 kHz /
48 kHz / 88.2 kHz / 96 kHz /
176.4 kHz / 192 kHz)
HDMI: 2ch linear PCM (32 kHz / 44.1 kHz /
48 kHz / 88.2 kHz / 96 kHz /
176.4 kHz / 192 kHz)
USB-C (DisplayPort Alt Mode): 2ch linear PCM (32 kHz / 44.1 kHz /
48 kHz / 88.2 kHz / 96 kHz /
176.4 kHz / 192 kHz)
Speakers 1 W + 1 W
Headphones 2 mW + 2 mW (32 Ω)
Input Terminals DisplayPort × 1, HDMI × 1, USB-C (DisplayPort Alt Mode) × 1 (each shared
with video signal)
Output Terminals Headphone jack × 1
