39
Chapter 6 Reference
●
Connection Procedure (Setup of USB Function)
1. Connect the monitor rst to a PC using the signal cable, and run the PC.
2. Connect the USB cable between the USB downstream port of the PC and the USB upstream port
of the monitor.
The USB hub function is set up automatically upon connection of the USB cable.
3. Connect the peripheral USB devices to the USB downstream port of the monitor.
USB
downstream
port
USB
upstream
port
6-6. Displaying Monitor Information
This function allows you to display the model name, serial number, usage time, resolution, and input
signal.
Procedure
1. Choose “Information” in the Setting menu, and press
.
The “Information” menu appears.
Attention
• When you turn on the monitor for the rst time, the usage time may be more than 0 due to a factory
inspection.
To Next Page
