Eizo FlexScan EV2750 User Manual

- 17 -
Chapter 2
Basic Adjustment/Setting
Function Setting Range Description Note
Auto EcoView On
Off
The ambient light sensor on the front of the monitor
detects the ambient brightness to automatically
adjust the screen brightness to a comfortable
level using the Auto EcoView function. The power
consumption of the backlight can be curtailed by
adjusting the brightness to an appropriate level.
This function can also mitigate eye strain and
tiredness caused by a screen that is too bright or
too dark.
Use the “Advanced Settings” to set the automatic
adjustment range to suit the monitor’s usage
environment or personal preference.
• Be careful not to block the ambient light sensor
on the lower side of the monitor when using the
Auto EcoView function.
• Even when the Auto EcoView setting is “On”,
the
operation switch on the front of
the monitor or color adjustment can be used to
change the “Brightness” to suit your personal
preference. Moreover, the manner in which
the Auto EcoView function changes brightness
also differs according to the changed value.
• When “DICOM” is selected for the color mode,
the Auto EcoView setting is turned “Off”.
Advanced
Settings
Maximum
Minimum
Brightness 0 to 100 Set the range for automatic brightness adjustment.
By setting the maximum value and minimum value
of the adjustment range in advance, the brightness
will be adjusted automatically within the set range.
• The maximum and minimum brightness values
cannot be set to the same value.
Ambient Light Bright
Standard
Dark
Using the default setting is recommended.
(Default setting: “Bright” for maximum value, “Dark”
for minimum value)
• For details on the “Ambient Light” setting, refer
to our web site (http://www.eizoglobal.com).
Reset - Return the advanced settings to their default values. -
EcoView Optimizer 2 On
Off
The monitor automatically adjusts the screen
brightness according to the white level of the input
signal.
This function can reduce power consumption while
maintaining the brightness specied by the input
signal.
• The setting is turned “Off” in the following
cases:
- When “sRGB”, “Movie” or “DICOM” is
selected for the color mode
- During PbyP display
• When set to “On”, the appearance of pale
colors may change. If this bothers you, set this
function to “Off”.

Eizo FlexScan EV2750 Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 89 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product color	White
Market positioning	-
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	67 W
Annual energy consumption	39 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Bundled software	EIZO ScreenManager Pro EIZO ScreenSlicer

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	545.2 mm
Weight (with stand)	7900 g
Depth (without stand)	48.5 mm
Width (without stand)	611.6 mm
Height (without stand)	359 mm
Weight (without stand)	5100 g
