Eizo FlexScan EV2750 User Manual

- 47 -
Chapter 6
Reference
6-4. Making Use of USB (Universal Serial Bus)
This monitor is equipped with a USB hub. It functions as a USB hub when connected to a USB-compatible PC, allowing the connection of peripheral USB
devices.
Note
• This product supports USB 3.0. When connecting to peripheral devices that support USB 3.0, high-speed data communication is possible (however, only when the USB cable
used to connect the PC and peripheral device is USB 3.0 compliant).
●
Required System Environment
• A PC equipped with a USB port
• Windows 8.1 / Windows 8 / Windows 7 / Windows Vista, Mac OS X 10.2 or later, Mac OS 9.2.2
• EIZO USB cable (UU200SS (USB 3.0))
Attention
• This monitor may not work depending on the PC, OS, or peripheral devices to be used. For USB compatibility of peripheral devices, contact their manufacturers.
• When the monitor is in power saving mode, devices connected to the USB downstream port will still work. Therefore, power consumption of the monitor varies with
connected devices even in power saving mode.
• When the main power of the monitor is off, a device connected to the USB downstream port will not operate.
●
Connection Procedure (Setup of USB Function)
1. Connect the monitor rst to a PC using the signal cable, and start the PC.
USB
downstream
port
USB
upstream
port
2. Connect the USB cable between the USB downstream port of the PC and the USB
upstream port of the monitor.
The USB hub function is set up automatically upon connection of the USB cable.
3. Connect a peripheral USB device to the USB downstream port of the monitor.

Eizo FlexScan EV2750 Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 89 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product color	White
Market positioning	-
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	67 W
Annual energy consumption	39 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Bundled software	EIZO ScreenManager Pro EIZO ScreenSlicer

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	545.2 mm
Weight (with stand)	7900 g
Depth (without stand)	48.5 mm
Width (without stand)	611.6 mm
Height (without stand)	359 mm
Weight (without stand)	5100 g
