Chapter 1
Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• 27.0″ wide format LCD
• Native Resolution 2560 × 1440 supported
• IPS panel with 89˚ horizontal and vertical viewing angles
• Supports three digital signal input interfaces (DisplayPort × 1, DVI-D (Dual Link/Single Link) × 1, HDMI × 1)
- DisplayPort (8-bit support)
*1
The DisplayPort input receives both image signals and audio signals via a single DisplayPort cable.
*1 When transmitting an audio signal using the DisplayPort cable, the graphics board must support audio output.
See “6-5. Specications” (page 48).
- HDMI
Supports PC signals via HDMI input.
The HDMI input receives both image signals and audio signals via a single HDMI cable.
• Equipped with “Picture by Picture (PbyP)” function that allows simultaneous display of multiple signals
Eliminates the need for changing between signals and leads to increased work efciency.
See “2-2. Switching Input Signals” (page 14).
• The Color Mode function allows the user to select the display mode optimum to the displayed image.
The Paper mode reproduces a printed paper effect on the monitor. In Paper mode, the amount of blue light emitted from the screen is reduced by changing the color tone
and controlling the brightness.
See “2-3. Switching Display Modes (Color Modes)” (page 15).
• Power saving functions
Suppressing power consumption
*2
reduces carbon dioxide emissions. This product is equipped with power saving functions.
- 0 W power consumption when the main power is off
Equipped with a main power switch.
When not using the monitor, you can turn off the main power supply so that the power is cut completely.
- Auto EcoView
The ambient light sensor on the front of the monitor detects the ambient brightness to automatically adjust the screen brightness to a comfortable level. Excessively
high brightness may increase power consumption and cause unwanted environmental effects. It may also lead to eye fatigue. The range of automatic adjustment can be
congured to personal preference.
See “Auto EcoView” (page 17).

Eizo FlexScan EV2750 Specifications

General

3D	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233 mm
Aspect ratio	16:9
Screen shape	Flat
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Viewable size, vertical	335.7 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 89 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 7, TUV/E, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, EAC
Product color	White
Market positioning	-
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	67 W
Annual energy consumption	39 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Bundled software	EIZO ScreenManager Pro EIZO ScreenSlicer

Weight and Dimensions

Depth (with stand)	245 mm
Height (with stand)	545.2 mm
Weight (with stand)	7900 g
Depth (without stand)	48.5 mm
Width (without stand)	611.6 mm
Height (without stand)	359 mm
Weight (without stand)	5100 g
