Eizo FlexScan EV2750

- 48 -
Chapter 6
Reference
6-5. Specications
LCD Panel Type IPS (Anti-Glare)
Backlight LED
Size 68.5 cm (27.0 inch)
Native Resolution 2560 dots × 1440 lines
Display Size (H × V) 596.7 mm × 335.7 mm
Pixel Pitch 0.233 mm
Display Colors 8-bit colors: 16.77 million colors
Viewing Angle (H × V, typical) 178˚ / 178˚
Response Time (typical) Gray-to-gray: 15 ms (overdrive setting: Off)
5 ms (overdrive setting: Enhanced)
Video Signals Input Terminals DisplayPort (HDCP) × 1, HDMI (HDCP)
*1
× 1, DVI-D (HDCP, Dual Link / Single Link) × 1
Digital Scanning Frequency
(H / V)
31 kHz to 89 kHz / 29 Hz to 31 Hz
*2
, 59 Hz to 61 Hz (49 Hz to 61 Hz for HDMI) (VGA TEXT: 69 Hz to 71 Hz)
Max. Dot Clock 241.50 MHz
USB Port Upstream port × 1, downstream port × 2
Standard USB Specication Revision 3.0
Communication Speed 5 Gbps (super), 480 Mbps (high), 12 Mbps (full), 1.5 Mbps (low)
Supply Current Downstream: Max. 900 mA per port
Audio Audio Input Format DisplayPort: 2 ch linear PCM (32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz)
HDMI: 2 ch linear PCM (32 kHz / 44.1 kHz / 48 kHz)
Speakers 1 W + 1 W
Headphones 2 mW + 2 mW (32 Ω)
Input Terminals Line: Stereo mini jack × 1
DisplayPort × 1, HDMI × 1 (shared with video signal)
Output Terminals Headphones: Stereo mini jack × 1
*1 HDMI CEC (or mutual control) is not supported.
*2 For details on applicable signals, see “1-3. Supported Resolutions” (page 11).
