Eizo FlexScan F35 User Manual

102
APPENDIX
VGA (text)
T 720 dots x 400 lines mode
Unit A B C D E F
µs 0.636 3.813 1.907 6.356 25.422 31.778
Dot 18 108 54 180 720 900
ms 0.381 0.064 1.111 1.556 12.712 14.268
Line 12 2 35 49 400 449
Frequencies: fd/28.322MHz, fH/31.468kHz, fV/70.087Hz
Interlace: Non
Sync Polarity: H/Negative, V/Positive
Video Signal Level: 0.7Vp-p/75Ohm
VESA
T 1024 dots x 768 (85Hz) lines mode
Unit A B C D E F
µs 0.508 1.016 2.201 3.725 10.836 14.561
Dot 48 96 208 352 1024 1376
ms 0.015 0.044 0.524 0.583 11.183 11.766
Line 1 3 36 40 768 808
Frequencies: fd/94.5MHz, fH/68.68kHz, fV/84.99Hz
Interlace: Non
Sync Polarity: H/Negative, V/Negative
Video Signal Level: 0.7Vp-p/75Ohm
Apple Macintosh
T 640 dots x 480 lines mode
Unit A B C D E F
µs 2.116 2.116 3.175 7.407 21.164 28.571
Dot 64 64 96 224 640 864
ms 0.086 0.086 1.114 1.286 13.714 15.000
Line 3 2 39 45 480 525
Frequencies: fd/30.24MHz, fH/35.00kHz, fV/66.67Hz
Interlace: Non
Sync Polarity: Separate sync, TTL, Negative
Video Signal Level: 0.7Vp-p/75Ohm
H
V
H
V
H
V
