EK-Quantum AM5 - Prepare AM5 Motherboard; Remove Original Hold-Down Clamps; Clean CPU Cold Plate

- 5 -
STEP 2
Clean the CPU cold plate using a non-abrasive cloth or Q-tip.
STEP 2
NON-ABRASIVE
CLOTH
CLEAN
STEP 1
Using a Philips-head screwdriver remove the four UNC 6-32 screws
securing the original plastic hold-down clamps around the socket as
shown in the illustration. Remove the hold-down clamps and store
them away.
PREPARING THE AM5 MOTHERBOARD
UNC 6-32 SCREW
HOLD-DOWN
CLAMPS
STEP 1
